Motor – Large Rear Drive Unit

Motor – Large Rear Drive Unit

	ASSEMBLY - PRODUCTION- SPORT REAR DRIVE UNIT - LDU ① Part Number: 1002633-01-U
	ASSEMBLY - REMAN - SPORT REAR DRIVE UNIT - LDU ① Part Number: 1025598-01-U
	BOLT HF M12X1.75X90 [10.9]-U-G720 ② Part Number: 2007064
	ASSY, SIDE MOTOR MNT, RSDU ④ Part Number: 1027591-00-D
	SIDE MOTOR MOUNT ASSEMBLY ④ Part Number: 1028034-00-B
	BOLT,M8-1.25X50,DIN6921,10.9,MTPT,ZF,PAT ⑤ Part Number: 1008724-00-B
	BOLT HF M8X30 PC109 ADH MAT (5A) Part Number: 1008722-00-A
	MOTOR DRAIN/REFILL PLUG ⑥ Part Number: 1008575-00-A
	OUTPUT AXLE SEAL ⑦ Part Number: 1065932-00-A
	O-RING,AS568A-143 ⑧ Part Number: 1007419-00-B
	NUT,M6-1.0,SEALING ⑨ Part Number: 1007714-00-A
	INLET MANIFOLD FITTING ASSEMLBY ⑩ Part Number: 1009997-00-B
	INLET MANIFOLD FITTING O-RING ⑪ Part Number: 1008806-00-A
	ENCODER,SENSOR,A1468 ⑫ Part Number: 1002722-00-C
	BOLT,M6-1.0X12,FHCS,DIN6921,G10.9,ZF720. ⑬ Part Number: 1008770-00-A
	ASY,HV COVER,INVERTER ⑭ Part Number: 1003783-00-B
	HIGH VOLTAGE INVERTER ENCLOSURE COVER O-RING ⑮ Part Number: 1003784-00-A
	ASY,PIPE,ROTOR,OUTLET,JW-C2 ⑯ Part Number: 1002731-00-A
	ASY,HARN,GND STRP,DRV INV TO CHASSIS ⑲ Part Number: 1009683-00-C
	FRONT TRANSMISSION MT BUSHING ⑳ Part Number: 6008779-00-D
	REAR TRANSMISSION MT BUSHING ② Part Number: 6008780-00-D
	BRKT, HV CBL TO DRV INV, 2MM THK, STL (22) Part Number: 1019545-00-A
	M6 - 1.0 X 12 (23) Part Number: 1011427-00-B
	HIGH VOLTAGE WARNING LABEL FOR PHASE OUT COVER (26) Part Number: 6008307
	SCR,HF,M6X16,[STL],SNZN,PTC,T2000. (*) Part Number: 1128091-00-B
	ATF, QUART (*) Part Number: 1031106-00-A
	ATF, DRUM (*) Part Number: 1061469-00-A
	SCREW, TORX, M4X8 (*) Part Number: 1014177-00-A
	BOLT BTNHD M10X1.50X57 [10.9] ZNAL-W (*) Part Number: 1004350-00-A
	BOLT HF M14X2.00X100 [10.9]-U-G720 (*) Part Number: 2007074
	BOLT - M6-1.0X30 (*) Part Number: 1009756-00-A
	SCREW - M6X16 (*) Part Number: 1077820-00-A
	FILL/DRAIN PLUG (*) Part Number: 1096865-00-B
