HV Harnesses

HV Harnesses

	HIGH VOLTAGE HARNESS - FRONT JUNCTION BOX TO FRONT DRIVE UNIT ① Part Number: 1038773-10-H
	HV HARN, FDU - FJB, MX ① Part Number: 1471181-00-C
	CABLE TIE-6MM SLOT-4.6-PA66HS- STUD MOUNT. (*) Part Number: 1019619-00-A
	HV HARN,RPD SPLTR-FJB,MX,V3 ② Part Number: 1507386-20-A
	HV HARN,RPD SPLTR-SDU,MS/X,V3 ③ Part Number: 1507386-01-A
	CBL TIE,6.5MM HOLE,4.6,PA66HS,FIR TREE (*) Part Number: 1017718-00-A
	UPPER BRACKET - FRONT JUNCTION CABLE ④ Part Number: 1106602-00-A
	LOWER BRACKET - FRONT JUNCTION CABLE ④ Part Number: 1106603-00-A
	HV HARN,RPD SPLTR-LDU,MX,MS2 ④ Part Number: 1507386-02-A
	SCREW,M8-1.25X18,HEX,STEEL,ZINC,PATCH,WITH WASHERS ⑤ Part Number: 1004405-00-A
	CBL TIE,110MM,4.6,PA66HS,UL94V2,FIR TREE ⑥ Part Number: 1022868-00-A
	O-RING,AS568A-006,SILICONE,A70 (*) Part Number: 1022644-00-A
	HV HARN,GEN3 CHGR-RPD SPLTR,MX ⑦ Part Number: 1063800-10-C
	HV HARN,GEN3 CHGR-RPD SPLTR,70MM2,MX ⑦ Part Number: 1500222-00-B
	O-RING,M4.5 IDX1,BUNA-N,A70 (*) Part Number: 1024689-00-A
	HV HARN,CHRG-INLET,MX,NA ⑧ Part Number: 1045978-10-G
	BOLT,M6-1.0X12,FHCS,DIN6921,G10.9,ZF720. ⑨ Part Number: 1008770-00-A
	NUT,HEX,FLG,M6-1.0X14[ST]-P-04 ⑩ Part Number: 1016227-00-A
	SCREW M6-1.0X18 - 8.8 ZINC WITH PATCH ⑪ Part Number: 1004373-00-A
	SCR,M6x1.0x20,PH,T30,ZnNi,PTCH ⑪ Part Number: 1021165-00-A
	O-RING,AS568A 2-211,HBNR,A70 ⑫ Part Number: 6009201-00-A
	TESLA, TAPE, ELECTRICAL (*) Part Number: 1015432-00-A
	HV CABLE GUIDE,RR SUBFRAME ⑭ Part Number: 1073543-10-A
	DKEPASSENGER - M6-1.0 - [8] - G1009 ⑮ Part Number: 1521216-00-A
	BRKT,70MM2_CBL,GEN3 CHGR,MX ⑯ Part Number: 1500224-00-B
