HV Harnesses

HV Harnesses

	HIGH VOLTAGE HARNESS - REAR DRIVE UNIT - LONG RANGE ① Part Number: 1588324-00-C
	HIGH VOLTAGE HARNESS - REAR DRIVE UNIT - PERFORMANCE ① Part Number: 1588325-00-C
	HIGH VOLTAGE HARNESS - FRONT DRIVE UNIT - PERFORMANCE ② Part Number: 1588323-20-B
	HIGH VOLTAGE HARNESS - FRONT DRIVE UNIT ② Part Number: 1588323-10-B
	HIGH VOLTAGE HARNESS - HEAT PUMP - HIGH VOLTAGE BATTERY ③ Part Number: 1613560-10-A
	HIGH VOLTAGE HARNESS - HEAT PUMP - HIGH VOLTAGE BATTERY ③ Part Number: 1613560-00-C
	HIGH VOLTAGE HARNESS - AC COMPRESSOR ④ Part Number: 1569594-00-B
	ASY,HARN,VEH TO HVC,HVPACK,P2 ⑤ Part Number: 1608422-00-C
	ASY,HARN,PYRO JUMPER,HVPACK,P2 ⑥ Part Number: 1609399-00-D
	HIGH VOLTAGE BUSBAR,CP,1P,P2 ⑦ Part Number: 1569000-80-A
	HIGH VOLTAGE BUSBAR,CP,P2 ⑦ Part Number: 1569000-20-A
	HVCON,PLG,6P,ASY,JUMPER,SX,P2 (*) Part Number: 1588001-00-A
	GROUNDSTRAP REAR DRIVE UNIT ⑧ Part Number: 1614473-00-B
	CHARGEP PORT SAFETY CAP - NACS ⑨ Part Number: 1506911-00-E
	HV INLET,SAFETY COVER,NA,CP,SX,P2 ⑨ Part Number: 1613385-00-A
	HIGH VOLTAGE BUSBAR CONNECTOR PLUG 600V ⑩ Part Number: 1507801-00-D
	NUT&WASHER[FL] - HF - M6 - [8] - ZNNI ⑪ Part Number: 1117846-00-A
	BOLT - HF - M6-1.0x23 - [88] - G1009[B] - MAT ⑫ Part Number: 1518561-00-A
	DKEPS,M6-1.0,[8],G1009 ⑬ Part Number: 1615815-00-A
	BOLT - HF - M6-1.0X45 - [88] - G0309 - SD ⑭ Part Number: 1530060-00-A
	BREAK-DSEMS,HX-TRI,M6X31,[SS],MAT. ⑮ Part Number: 1521609-00-A
	DPT,PF,40-1.46X14,STL,G1009[B] ⑯ Part Number: 1464173-00-A
	BOLT, TE, M14X2X111,STL[109],ZNNI+WAX ⑱ Part Number: 1490534-00-A
	BOLT -M6-1.0x12,[58],SNZN ⑲ Part Number: 1526016-00-A
	BOLT,HF,M8-1.25x22,[109],G0110,MAT ⑳ Part Number: 1552447-00-A
	HARNESS ASSEMBLY - REAR DRIVE UNIT - PERFORMANCE (*) Part Number: 1591240-00-C
