High Voltage Battery Assembly

High Voltage Battery Assembly

	ASY,HV BATTERY,PLAID,MDLSX ① Part Number: 1111111-30-H
	HV BATTERY,PLAID, REMAN ① Part Number: 1728253-01-H
	CL SPACER,14.5ID,26OD,6H,STL,G1009 (*) Part Number: 1606836-00-B
	ASY,FAC,ENCLOSURE,HVB,PALLADIUM ② Part Number: 1594171-00-D
	COVER,ACCESS,REAR,HV P2. ③ Part Number: 1672294-00-B
	SEALANT, LIQUID GASKET 1216E ④ Part Number: 1089956-00-A
	P2 PYROTECHNIC FUSE COVER ⑤ Part Number: 1594155-00-B
	ASY,CABLE,GND,HV PACK,P2,MSX ⑥ Part Number: 1618245-00-B
	Cable Tie/Offset Fir Tree w/Disc (*) Part Number: 1030956-00-A
	SCREW,HF,M6X16,STL,ZNFL,T2000 (*) Part Number: 1116851-00-A
	BOLT,TE,M6-1.0X14,[88],G1009,CA. (*) Part Number: 1508009-00-A
	SEAL,FAC,ENCLOSURE,HVB,P2 ⑦ Part Number: 1658481-00-F
	BOLT,HF,M5-0.8X13,[109],STL,G1009,A02 ⑧ Part Number: 1679466-00-A
	BOLT HF M5x10 PC88 SEAL ⑨ Part Number: 1036360-00-A
	BOLT,P-LOBE,M5-0.8X16,[109],G1009,SM ⑩ Part Number: 1643872-00-A
	HVCON,HDR,6P,ASY,OUTER,SX,P2 ⑪ Part Number: 1588002-00-A
	HVCON,HEADER,90DEG,DU,SX,P2 ⑫ Part Number: 1567101-10-A
	HVCON,HEADER,90DEG,DU,SX,P2 ⑫ Part Number: 1567101-11-A
	BOLT,5LOBE,M6X13,S[10X8],[88],G1009,CMAT (*) Part Number: 1095042-00-C
	SEAL,NVH,ENCLOSURE COVER,P2,HVBATT ⑬ Part Number: 1623028-00-A
	HVCON,HEADER,0DEG,DU,SX,P2 ⑭ Part Number: 1567101-20-A
	HIGH VOLTAGE CONNECTOR - HEADER - 0 DEGREES - DU ⑭ Part Number: 1567101-21-A
	BOLT,10IH,M6-1x12,[88],G1009,SM (*) Part Number: 1655856-00-B
	ASY, FLOOD PORT 2.0 ⑮ Part Number: 1635050-00-A
	THERMAL VENT ASSY, HVB, P2 (*) Part Number: 1667216-02-A
	BREATHER - NITTO ZH - PLUG ⑯ Part Number: 1108907-00-B
	BOLT,PF,M4X10,STL[88],ZNNI,PIL ⑰ Part Number: 1096312-00-B
	SCR,M10-1.50X25,HF,MPNT,STL10.9,ZNC,PTCH (*) Part Number: 1004383-00-C
	T2000 - TE - M5X10 - STL - ZNNI - SEREAR - CA (*) Part Number: 1140104-00-A
	BOLT,EPL,M8-1.25X119,[149],G0110,SM (*) Part Number: 1626581-00-A
