 | MDL S,LHD,THERM SYS,COOLANT BOTTLE ASY ① Part Number: 1032227-00-A | | |
| COOLANT RESERVOIR ASSEMBLY ① Part Number: 6007339-00-C | | |
| PRESSURE CAP,COOLANT RESERVOIR ② Part Number: 6007612-00-B | | |
| NUT HF M6-1.00[8]ZNAL. ⑤ Part Number: 2007207 | | |
| ASY - HOSE (BATT) - HEATER TO BATTERY ⑥ Part Number: 6008305-00-E | | |
| CLAMP 27mm HOSE POPP ⑧ Part Number: 1006524-00-A | | |
| ASY - HOSE (BATT) - BATTERY TO RESERVOIR ⑨ Part Number: 6007349-00-F | | |
| HOSE (PT), RESERVOIR TO 4 WAY VALVE ASSY ⑩ Part Number: 6007346-00-D | | |
| VALVE 4-WAY ⑫ Part Number: 6007370-00-F | | |
| 4 WAY VALVE BRACKET ⑬ Part Number: 1006146-00-A | | |
| BOLT TRX MP M6 - 1.00X20 D12 [8.8] ZNAL ⑭ Part Number: 1005814-00-A | | |
| THERMAL SYSTEM,ELECTRIC BATTERY HEATER ⑮ Part Number: 1038901-00-K | | |
| CONNECTOR, HV, COOLANT HEATER (*) Part Number: 1025005-00-A | | |
| REAR HOLDER FOR HIGH VOLTAGE CONNECTOR (*) Part Number: 1021413-00-A | | |
| BOLT - GROUND STRAP DRIVE UNIT SIDE -M6-1.25x16 ⑰ Part Number: 1006381-00-A | | |
| HEX BOLT - M6 - 1.00X25 ⑱ Part Number: 1005817-00-A | | |
| ASY,COOLANT CX,VEH SIDE, MS AND MX ⑲ Part Number: 1003117-00-H | | |
| SCREW M6-1x16 (22) Part Number: 1004341-00-B | | |
| ASY - HOSE (BATT) - 4 WAY VALVE TO PUMP (23) Part Number: 6007344-00-F | | |
| COOLANT PUMP, 50W, LT, FOR SERVICE (24) Part Number: 1057257-01-G | | |
| COOLANT PUMP ASSY, FOAM ISOLATED (24) Part Number: 1067473-00-H | | |
| PUMP ISOLATOR (25) Part Number: 1067474-00-D | | |
| BRKT PUMP BATTERY COOLANT (26) Part Number: 6009276-00-C | | |
| BOLT M6 - 1.00X18 T30 ECOFIX FLANGE HD (27) Part Number: 1024353-00-A | | |
| CHILLER TO PUMP 2 HOSE ASSEMBLY (28) Part Number: 6007345-00-E | | |
| ASY - HOSE (BATT) - PUMP TO HEATER (29) Part Number: 6007354-00-E | | |
| VALVE 3-WAY, MODEL S (30) Part Number: 6007384-00-F | | |
| BRKT - CHILLER BYPASS (31) Part Number: 1003762-00-A | | |
| HOSE (BATT), PUMP 1 TO 3WVLV ASSY, MS (32) Part Number: 6007350-00-E | | |
| NUT - M8-1.25 - HF - STEEL[10] - ZNAL - BLACK (33) Part Number: 1006628-01-A | | |
| 3 WAY VALVE TO CHILLER HOSE ASSEMBLY (34) Part Number: 6007347-00-C | | |
