 | ASSEMBLY ANCILLARY BAY COVER ① Part Number: 1494171-00-A | | |
| INSULATOR,HV JOINT (*) Part Number: 1097686-00-C | | |
| ASSEMBLY-PROBE LID-ANCILLARY BAY COVER-HVBAT ② Part Number: 1107566-00-C | | |
| BREATHER - NITTO ZH - PLUG ② Part Number: 1108907-00-B | | |
| SEAL PROBE LID- HIGH VOLTAGE BATTERY ③ Part Number: 1108958-00-A | | |
| BOLT,5LOBE,M6X19,[109],ZNNI,MAT,PTP,SEAL ④ Part Number: 1117669-00-A | | |
| ASSEMBLY - HARNESS - ALL WHEEL DRIVE - ANCILLARY BAY ⑤ Part Number: 1732579-00-A | | |
| ASSEMBLY - HARNESS - REAR WHEEL DRIVE - ANCILLARY BAY ⑤ Part Number: 1732579-01-A | | |
| HIGH VOLTAGE SYSTEM CONTROLLER ⑥ Part Number: 1106394-01-P | | |
| SCREW,TE,50X20,STL,DPT,R,ZNNI. (*) Part Number: 1107984-00-B | | |
| BOLT,TE,M6-1.0X14,[88],G1009,CA. (*) Part Number: 1508009-00-A | | |
| HINGE TRAY - HIGH VOLTAGE CONTROLLER ⑦ Part Number: 1101626-00-H | | |
| COVER, AC INLET TERMINAL, 1PH, M3 ⑧ Part Number: 1110932-00-A | | |
| ASSEMBLY POWER CONVERSION SYSTEM - 48AMP - 1PHASE ⑨ Part Number: 1135558-04-A | | |
| ASSEMBLY POWER CONVERSION SYSTEM - 48AMP - 1PHASE ⑨ Part Number: 1135558-54-A | | |
| ASSEMBLY POWER CONTROL SYSTEM (PCS)- 32 AMPS- 1PHASE ⑨ Part Number: 1135558-03-D | | |
| JUMPER,DCDC PCS TO VEH,PRESS WELD,M3 (*) Part Number: 1077114-10-E | | |
| INSULATOR ACCESS - FASTCHARGE ⑩ Part Number: 1088607-00-G | | |
| COVER - LEFT TERMINALS - ANCILLARY BAY ⑪ Part Number: 1110699-00-E | | |
| HIGH VOLTAGE - CONTACTOR ASSEMBLY ⑫ Part Number: 1089334-02-K | | |
| NUT&WSHR[DBL],M8,BRS,SEALER. ⑬ Part Number: 1104654-00-B | | |
| DSEMS,HEX,M8-1.25x23,[98],G1009,SDOG,WAX ⑭ Part Number: 1104475-00-F | | |
| BUSBAR FAST CHARGE - INPUT - POSITIVE ⑮ Part Number: 1084660-00-C | | |
| BUSBAR FAST CHARGE - INPUT - NEGATIVE ⑯ Part Number: 1084659-00-D | | |
| BUSBAR - FAST CHARGE CONTACTOR TO DIRECT CURRENT BUSBAR - NEGATIVE ⑰ Part Number: 1084661-00-C | | |
| BUSBAR - FAST CHARGE CONTACTOR TO DIRECT CURRENT BUSBAR - POSITIVE ⑱ Part Number: 1084662-00-C | | |
| ASSEMBLY - FAST CHARGE CONTACTOR - HIGH VOLTAGE BATTERY ⑲ Part Number: 1095145-01-J | | |
| BOLT,TE,M5X22,[88],ZN,MAT. ⑳ Part Number: 1112243-00-A | | |
| DISCONNECT,BATTERY,PYRO DISCONNECT ② Part Number: 1064689-00-J | | |
| ASSEMBLY SHUNT (22) Part Number: 1078835-00-G | | |
| COVER - MODULE 2 TO PYROFUSE - HIGH VOLTAGE BATTERY (23) Part Number: 1096401-00-C | | |
| COVER,ACCESS,FC ASY,HVBAT (24) Part Number: 1107310-00-B | | |
| ASSEMBLY INSULATOR- LOWER- FASTCHARGE ASSEMBLY (24) Part Number: 1110933-00-F | | |
| ASSEMBLY HOSE - OUTLET FROM POWER CONTROL UNIT (PCS) (25) Part Number: 1095766-00-F | | |
| ASSEMBLY HOSE- INLET TO POWER CONTROL UNIT (PCS) UNIT (26) Part Number: 1095763-00-G | | |
| O RING - PCS HOSE (*) Part Number: 1091895-00-A | | |
| SCREW TRX WASHER M5X1.8-16 ZN. (28) Part Number: 1009335-00-A | | |
| NUT&WSHR[CC],M5,STL[8],ZN (30) Part Number: 1104458-00-A | | |
| INSULATOR,ACCESS,FUSES (31) Part Number: 1088609-00-B | | |
| FUSE - 63A - 700VDC - 14X51 (31) Part Number: 1611034-00-A | | |
| FASTENER, SCREW, TORX30, M6-1.00X10MM (*) Part Number: 1006772-00-A | | |
| COVER - BUSBAR - SHUNT TO MOD 3 (32) Part Number: 1096402-00-C | | |
| CABLE TIE,200X4.6X2X1.5,PA66 (32) Part Number: 1117013-00-A | | |
| ASSEMBLY HARNESS - CHARGER OUTPUT TO DIRECT CURRENT (33) Part Number: 1078426-00-E | | |
| COLLECTOR PLATE ATTACH - FLOOD PORT SENSOR (34) Part Number: 1458000-00-A | | |
| BOLT HF,M5X10,STL[88],ZNNI 6 (34.3) Part Number: 1115833-00-B | | |
| BOLT,5LOBE,M6X13,S[10X8],[88],G1009,CMAT (*) Part Number: 1095042-00-C | | |
| SUPPORT - HINGE - HIGH VOLTAGE CONTROLLER (35) Part Number: 1111040-00-C | | |
| BOLT&WSHR[BDL],HX,M5X21,[88],ZNNI.MAT (*) Part Number: 1115777-00-A | | |
| COVER - ANCILLARY BAY BUS - LEFT HAND (36) Part Number: 1111869-00-F | | |
| ASSEMBLY HARNESS- AC FILTER- 4P 240V (37) Part Number: 1092739-00-E | | |
| ASSEMBLY DC LINK- POSITIVE (37) Part Number: 1095891-00-G | | |
| BRKT, AC INLET HARNESS, ANCILLARY BAY, M3 (38) Part Number: 1108199-00-B | | |
| CABLE TIE-6MM SLOT-4.6-PA66HS- STUD MOUNT. (*) Part Number: 1019619-00-A | | |
| ASY,DC INPUT,1PH,M3 (*) Part Number: 1084645-00-I | | |
| INSULATOR - ACCESS - SHUNT (*) Part Number: 1088608-00-E | | |
| HIGH VOLTAGE DUMMY HEADER- 4P (*) Part Number: 1108281-00-B | | |
| SCREW,HW,M6X22,STL,ZN,T2000 4 (*) Part Number: 1115578-00-C | | |
| NUT HF M6-1 0 8 ZNNI B (*) Part Number: 1116867-00-A | | |
| KIT, ANCILLARY BAY HV INSULATORS, M3 (*) Part Number: 1467483-00-A | | |
| DC INPUT HEADER ASSEMBLY-2P- 600V (*) Part Number: 1507802-00-B | | |
