Air Conditioning Pipes and Hoses

Air Conditioning Pipes and Hoses

	SUCTION LIQUID AIR CONDITIONING LINE ASSEMBLY WITH TXV VALVE - R134A (WITHOUT PRESSOR AND TEMPERATURE SENSOR) ① Part Number: 1004293-00-G
	SUCTION LIQUID AIR CONDITIONING LINE ASSEMBLY WITH TXV VALVE - R1234YF ① Part Number: 1019542-00-A
	SUCTION LIQUID AIR CONDITIONING LINE ASSEMBLY WITH TXV VALVE ?- HVCC - R134A ① Part Number: 1028400-00-D
	ASY,AC LINE,R134A,SUCT LIQ TXV,DM,MDL S ① Part Number: 1031670-00-F
	AC LINE ASY,R134A,SUCT LIQ TXV,DM,MDL S ① Part Number: 1031670-00-H
	ASY,AC LINE,R1234YF,SUCT LIQ TXV,LEFT HAND DRIVE ① Part Number: 1033646-00-D
	SNSR - REFRIGERANT PRESS AND TEMP - LOW (*) Part Number: 1008515-00-C
	O-RING, HNBR 13.52 X 2.47 (*) Part Number: 1024766-00-A
	REFRIGERANT PRESSURE SENSOR DUMMY PLUG ASSEMBLY (*) Part Number: 1021029-00-A
	O-RING, HNBR 6.07 X 2.18 (*) Part Number: 1024772-00-A
	O-RING, HNBR, 12.22MM (ID) X 2.48MM (T) (*) Part Number: 1010832-00-A
	O-RING, HNBR 15.22 X 2.48 (*) Part Number: 1024770-00-A
	HIGH SIDE FILL CAP, R134A (*) Part Number: 1036693-00-A
	LOW SIDE FILL CAP, R134A (*) Part Number: 1036694-00-A
	HIGH SIDE FILL CAP, R1234YF (*) Part Number: 1036695-00-A
	LOW SIDE FILL CAP, R1234YF (*) Part Number: 1036696-00-A
	BOLT HF M6 - 1.00X20[8.8]ZNALW. ② Part Number: 1009420-00-A
	HEX BOLT - M6 - 1.00X25 ③ Part Number: 1005817-00-A
	AC LINE - CHILLER TO COMP ④ Part Number: 1009293-00-A
	O-RING, HNBR 10.92 X 2.47 (*) Part Number: 1024762-00-A
	AC LINE - CONDENSER TO EVAP 2 ⑤ Part Number: 1004294-00-A
	LOWER LIQUID AND CHILLER AIR CONDITION LINE ASSEMBLY - DUAL MOTOR (*) Part Number: 1038025-00-A
	NUT HF M6-1.00[8]ZNAL. ⑥ Part Number: 2007207
	MDL S,AC LINE ASY,DISCHARGE ⑦ Part Number: 1028401-00-G
	ASY,AC LINE,DISCHARGE,DM,MDL S ⑦ Part Number: 1031671-00-I
	AC LINE, COMPRESSOR TO CONDENSER ⑦ Part Number: 6007386-00-B
	SNSR-REFRIGERANT PRESS AND TEMP- HI (*) Part Number: 1008516-00-C
	HNBR O-RING - 14.55MM OUTER DIAMETER X 9.75MM INNER DIAMTER X 2.4MM THICKNESS (*) Part Number: 1020654-00-A
	ASSY - BATTERY CHILLER AND TXV, R134A W/O SOLENOID ⑧ Part Number: 1007476-00-E
	BATTERY CHILLER AND TXV VALVE ASSEMBLY WITHOUT SOLENOID - R1234YF ⑧ Part Number: 1019540-00-C
	ASY,HARN,DMYPLG,SOLENOID (*) Part Number: 1026980-00-A
	BOLT HEX FL M8-1.25X25 8.8 -M-ZINC ALUMINUM ⑨ Part Number: 1005805-00-A
	AC LINE, CONDENSER 1 TO CONDENSER 2 ⑩ Part Number: 6007733-00-A
	TXV EVAPORTATOR VALVE ASSEMBLY WITH SOLENOID - R1234YF ⑪ Part Number: 1019544-00-B
	VALVE ASY, TXV W/ SOL R134A - EVAPORATOR ⑪ Part Number: 6008481-00-B
	BLT TRX M6-1.00X60 8.8 M ZNAL ⑫ Part Number: 1005810-00-A
	COOLANT VALVE CONNECTOR DUMMY PLUG ASSEMBLY (*) Part Number: 1020949-00-A
	MSF SEAL - 8MM (*) Part Number: 1529977-00-A
	MSF SEAL 5/8 INCH (*) Part Number: 1529988-00-A
