Air Conditioning Pipes and Hoses

Air Conditioning Pipes and Hoses

	AC LINE ASY,R134A,SUCT LIQ TXV,MDL X ① Part Number: 1032222-00-F
	AC LINE ASY,R1234YF,SUCT LIQ TXV,MDL X ① Part Number: 1046265-00-D
	AC LINE ASY,R134A,SUCT LIQ TXV,NO RHVAC ① Part Number: 1056257-00-D
	AC LINE,R1234YF,SUCT LIQ TXV,NO RHVAC ① Part Number: 1056259-00-D
	TXV EVAPORTATOR VALVE ASSEMBLY WITH SOLENOID - R1234YF (*) Part Number: 1019544-00-B
	VALVE ASY, TXV W/ SOL R134A - EVAPORATOR (*) Part Number: 6008481-00-B
	VALVE ASY, TXV- REARHVAC (*) Part Number: 1050969-00-D
	BLT TRX M6-1.00X60 8.8 M ZNAL ② Part Number: 1005810-00-A
	AC LINE ASY,SUCT LIQ JUMPER,MDL X ③ Part Number: 1054664-00-E
	AC LINE ASY,SUCT LIQ JUMPER,MDL X ③ Part Number: 1486469-00-C
	AC LINE ASY,DISCHARGE,MDL X ④ Part Number: 1032196-00-E
	SNSR-REFRIGERANT PRESS AND TEMP- HI (*) Part Number: 1008516-00-C
	AC LINE ASY,SUCT LIQ TO RH ROCKER,MDL X ⑤ Part Number: 1037334-00-H
	AC LINE ASY,LH ROCKER,MDL X ⑥ Part Number: 1032422-00-D
	AC LINE ASY,R134A,LEFT HAND RCKR TO RHVAC,MDL X ⑦ Part Number: 1032423-00-E
	NUT - M8-1.25 - HF - STEEL[10] - ZNAL - BLACK ⑧ Part Number: 1006628-01-A
	NUT HF M6-1.00[8]ZNAL. ⑨ Part Number: 2007207
	HEX BOLT - M6 - 1.00X25 ⑩ Part Number: 1005817-00-A
	ASSY, BATT CHILLER AND EXV, MS AND MX (*) Part Number: 1037357-00-G
	CHILLER-EXV ASY, SLIM-LINE (*) Part Number: 1486609-00-A
	EXV (*) Part Number: 1039040-00-G
	EXV, CHILLER ASY, MX (*) Part Number: 1487414-00-A
	MSX_EXV COIL - SERVICE KIT (*) Part Number: 1142538-00-C
	CHILLER BRKT, FR SUBF, MX (*) Part Number: 1027546-00-C
	BRKT, CHILLER, MX (*) Part Number: 1486472-00-C
	CHILLER BRKT, FR SUBF, MX (*) Part Number: 1027546-00-B
	O-RING, HNBR, 12.22MM (ID) X 2.48MM (T) (*) Part Number: 1010832-00-A
	O-RING, HNBR 6.07 X 2.18 (*) Part Number: 1024772-00-A
	O-RING, HNBR 15.22 X 2.48 (*) Part Number: 1024770-00-A
	SNSR - REFRIGERANT PRESS AND TEMP - LOW (*) Part Number: 1008515-00-C
	HNBR O-RING - 14.55MM OUTER DIAMETER X 9.75MM INNER DIAMTER X 2.4MM THICKNESS (*) Part Number: 1020654-00-A
	MSF SEAL - 8MM (*) Part Number: 1529977-00-A
	MSF SEAL 5/8 INCH (*) Part Number: 1529988-00-A
